TOMAGAL™
Matierial
Properties
PROPERTIES
-
Class A1 Fire classification under EN 13501-1:2018 standards, ensuring maximum fire safety and protection.
-
Meeting strict E1 Class requirements, the material exhibits no detectable formaldehyde emissions (< 0.080 mg/m³), promoting optimal healthy indoor air quality.
-
The surface is made of inorganic materials resists insects of most kind.
-
Engineered for environmental durability, the material achieves a "0" rating in 28-day fungal resistance testing, indicating absolutely no observable mold or fungal growth.
-
Maintains excellent structural stability in highly humid environments. After 32°C at 90% relative humidity for 48 hours of heavy moisture exposure, the panel shows a minimal deflection of just 1.6 mm.
AVAILABLE Products
SUBSTRATES
Plywood
Application RecommendationCabinet, Door, Furniture Top
Thickness Available4 mm - 22 mm
Fiber Cement Board
Application RecommendationWall and Ceiling
Thickness Available10 mm - 18 mm
Thickness AvailableAluminium
Curve Making
Application Recommendation3 mm - 5 mm
AVAILABLE SYSTEMS
Custom panel sizes are available for selected substrates and designs.
Please contact our team for specific details and availability.
ADHESIVE
METHODS
-
Mount directly onto plywood, OSB , calcium silicate or fiber cement boards.
-
Apply directly after treating the surface with a primer, ensuring moisture and adhesion strength.
-
Install directly over existing decorative panels (MDF, SPC, etc.). Existing tile or marble must be firmly attached and treated with a primer before applying adhesive.
-
Direct installation is prohibited; wallpaper must be completely removed, and painted surfaces must be stripped down to the bare wall prior to installation.
AVAILABLE DIMENSIONS
1200 × 3000 mm
1200 × 2400 mm
Custom size available*
Custom panel sizes are available for select substrates and designs. Please contact our team for specific details and availability.
